DESCRIPTION

Basic Info.

Model NO.	FASTLINK
Surface Finishing	Finished
Single Gross Weight	190.000kg
Selling Units	Single Item
The Height of The Door Panel	Embossed on The Metal Surface
Aterial	Aluminum Alloy/Steel
Opening Mode	Electric/Manual
Project Solution Capability	Total Solution for Projects
Door Pane	Pusandwich Panel,Total Thickness 42mm
Design Style	Modern
Feature	Anti-Theft
After-Sale Service	Online Technical Support
Speed	0.25m/S
Panel	Anti-Pinch Hand Design
Door Material	Aluminum Alloy
Application	Villa,Commercial Housing
Single Package Size	406.4X66.4X97.1cm
Specification	OEM
Trademark	FASTLINK
Origin	Shanghai, China
HS Code	85308000
Production Capacity	50000 PCS/Year

Product Description

Important attributes
Country of Origin	China
Brand	Shanghai Fastlink Door Company
Industry attributes	Garage Door
Product	Garage Door
Product model
Material	Aluminum alloy/steel
Features	Thermal insulation, wind resistance, anti-theft, sealing, safety, intelligent control, small space occupation, easy installation and maintenance
Application scenarios	Private vehicle parking garage (parking spaces with low switching frequency such as villas, commercial housing, underground parking lots, etc.)
Other attributes
Opening mode	Electric/manual
Size	Minimum size :W2000mmH2000mm(6'7 W 6'7 H) Maximum size :W11500mmH6000mm(37'9 W 19'8 H)
Door panel	PU sandwich panel, total thickness 42mm
Polyurethane	Huntsman brand, freon-free, density: 48kg/m³, closed-cell rate>95%
Surface operation	Embossed on the metal surface
The height of the door panel	500mm
Rail	Patented wind-resistant track design
Rail connection method	Bolted connection (easy to maintain)
Lifting mode	Vertical Lift/High Lift/Standard Lift(Right Angle lift)
Speed	0.25m/s
Motor	Garage door dedicated DC motor, precise positioning; Single 220V, power: 70w-200w Chain rail transmission, smooth switch, steel wire rope will not fall off.
Spring	High-strength spring steel, shot blasting electrophoresis treatment, corrosion resistance, not easy to rust, maintenance-free
Open mode	Optional button switch, remote control, Bluetooth, license plate recognition, mobile app, manual
Wind resistance rating	700pa(GB/T 7106-2008)
Thermal Insulation Property	K=1.1W/(.K)
Watertight	Grade 1(GB/T 7106-2008) watertight rank 1
Airtightness	Grade 7(GB/T 7106-2008) Air tightness rank 7
Color	RAL9002/RAL9006/RAL7040/RAL7045
the apparatus of security
Rebound when encountering obstacles	When encountering obstacles during the descent of the door, the door will automatically sense and immediately stop descending and ascend to the highest point.
Spring	Anti-breakage
Panel	Anti-pinch hand design
Semi-closed track hand guard design	The handguard protection makes the door safer during use, and the track and auxiliary rail are removeable, which is easy to replace and effectively reduce the maintenance cost.
Wire rope built-in safety design	The wire rope is placed on the inside of the track, which is not easy to touch and avoid being accidentally pinched
Infared safty device	optional
Latch locks	optional
Windows	optional
Vent Windows	optional
Passdoor-in-door	optional
Internal and external door locks	optional
Production Facilities
Door panel production	Germany Bayer Hennecke imported automatic door panel production line
Component production	Fully automatic CNC cutting/ making hole equipment, prefabricated mounting holes for easy installation
Rail production	Automated/Modular Molding Machine
Electrical production	Modular production line
Capabilities for Engineering Solutions
Product selection	Match scenario
Drawing	Product solutaion drawing
Installation guide	Product installation guide video, installation guide manual
Case Reference	Case videos, case pictures, case descriptions
Packing box shipping information
Sales Units	one set of
Individual package size	Wooden box size: 4064X664X971, 1 wooden box
Gross weight	320kgW2800*H2500
Time to Market
Time to Market	3000sets of door per month
lead time
Lead time	30days
sample
Maximum order quantity for sample	2
Price of the sample	100$
option
Passdoor-in-door	optional
Window	optional
Door panel color	optional
Vent Windows	optional
Internal and external door locks	optional
certificate
Certification	CECPRUL
after-sale service
After-sale service	Dealer local service or remote service, user manual, quick response
Warranty	one year
tiered pricing	2 sets 20 sets 50 sets

Q&A

Is the lnsulated Sectional Door safe to use?

The Fastlink Sectional Door has passed CE certification and is designed with comprehensive safety considerations, such as: the bottom door panel rebounding when encountering resistance during descent;Design of anti breakage safety protection for steel wire rope; Twisted spring anti breakage safety protection design; Door panel anti pinch design, etc., can be selected with confidence. The manufacturer provides a complete operation and maintenance support manual

Will a garage door resist wind better than a roll-up door?

The unique structural design of the garage door has a strong wind resistance, it can meet at least 700Pa wind resistance. in some coastal cities where typhoons pass through the area, Fastlink garage door can withstand the test of the typhoon, still safe and sound.

What is the minimum amount of installation space required above the door opening?

Minimum installation space above the door opening is 350mm; Minimum installation space on each side of the door opening is 150 mm.

What is the life span of a garage door?

Normal maintenance can be used for more than 10 years. Correct use and regular maintenance will help the garage door to last more years;
